VMM-1510

VMM-1510

Model number: VMM-1510

Be Applied to Mechanical ,,Electronic ,Plastic Fields etc.

Function of Data Processing,Displaying,Input,Output,

With RS-232 Interface

With Quick Measuring Software

Obviously assistant laser position system

FEATURES

Metal Table Size(mm): 354X228

Glass Table Size(mm): 210X160

X,Y-axis Travel(mm): 150X100

Z-axis Travel(mm): 200

Resolution(mm):0.0005

X,Y-axis Accuracy(um):≤3+L/200

Measuring Software : Quick Measuring

Net Weight(kg): 100

Measuring Software: Quick Measuring

Dimensios(mm):600x530x950

Video System: 1/3“  Color CCD Camera , 0.7~4.5 Zoom Lens,Video Total Magnification:30X~230X ,Object View:7~1.1mm LED adjustable Light Source

Power:180V~260V(AC),50HZ

PRODUCT ADVANTAGES VMM-1510

1.   it can effectively complement the measurement and observation.


2.   stable performance


3.   high precision


4.   simple operation


5.   easy maintenance


6.   Simple structure, strong bearing capacity, the workpiece placed open space, handling convenience.


Product Applications

The perfect vision system for non-contact measurement and further inspection of Stamped and injected parts,Plastic parts, injection moulds,Electronic and other components commonly used in silk screen printing as well as the lead industry among others。


Packing ,transportation and after sales service

1.   One years warranty for the mother board.

2.   Life-long maintenance service for the product.

Packing : wooden case.

Delivery time : 2 working days after receive the payment.
